KV4315G

Applicable Wires: 0.5-4 mm²

Operating temperature: -25℃~95℃

Rated voltage: 250 V/600 V

Rated current: 32 A

Material of connectors shell: Nylon PA66/Polycarbon PC

Material of conductive parts: Brass Tin/plated

Product Description About Us

Characteristics:

  • Robust & Long-Lasting; The KV4315G(3 in 15 out) lever terminal blocks feature a durable PA66/PC flame-retardant housing with excellent resistance to high temperatures, aging, and corrosion for reliable long-term performance.

  • Effortless & Secure Wiring: Their user-friendly lever mechanism allows quick, tool-free installation of 0.5-4.0mm² conductors, ensuring instant, vibration-proof connections.

  • Compact & Versatile: With a 600V/24A rating and UL94 V-0 compliance, these space-saving, industrial-grade terminals suit diverse applications—from hotels and homes to warehouses and control panels—while enabling maintenance-free, reusable connections.

Technical Parameters

Applicable Wire Gauge 0.5-4mm²/28-12  AWG
Temperature range -25℃~95℃
Rated Voltage 250V/600V
Rated Current 32A
Contact resistance ≤0.015Ω
Insulation resistance ≥1000mΩ
Material Shell: Nylon PA66/Polycarbon PC(Nyion)UL94V-2(0)
Contact piece: Brass Tin/plated
Spring buckle: 301 stainless steel
Reach 15 tests
Allowance ±0.05mm
Suitable guide TH35-7.5
×
