KV448 Terminal Blocks Tool-Free Strength

Characteristics:

Industrial-Grade Reliability: The KV448(4 in 8 out) lever terminals feature rugged PA66/PC flame-resistant housing that endures extreme temperatures, corrosion, and aging for long-lasting performance.
Effortless Tool-Free Wiring: The intuitive lever mechanism allows quick, secure connections—simply flip, insert (0.5-4.0mm² wires), and press down for instant termination.
Compact & Versatile Design: Combining sleek aesthetics with robust functionality, these terminals provide maintenance-free solutions for commercial, residential, and industrial applications.

Technical Parameters

Applicable Wire Gauge	0.5-4mm²/28-12 AWG
Temperature range	-25℃~95℃
Rated Voltage	250V/600V
Rated Current	32A
Contact resistance	≤0.015Ω
Insulation resistance	≥1000mΩ
Material	Shell: Nylon PA66/Polycarbon PC(Nyion)UL94V-2(0)
	Contact piece: Brass Tin/plated
	Spring buckle: 301 stainless steel
Reach	15 tests
Allowance	±0.05mm
Suitable guide	TH35-7.5
