KV773-10

Applicable Wires: 0.75-4 mm²

Operating temperature: -25℃~110℃

Rated voltage: 250 V

Rated current: 24 A

Material of connectors shell: Nylon PA66 / Polycarbon PC

Material of conductive parts: Brass Tin/plated

Characteristic：

Fast & Secure Wiring: The KV773-10 push-in terminal blocks enable quick, tool-free connections for solid wires (0.75-4mm²), simplifying installation in both surface and flush-mounted applications.
Reliable Performance: With a 250V/24A rating, these terminals ensure safe, maintenance-free operation for residential and commercial electrical systems.
Versatile & Error-Proof: Designed for fault-free installations, the modular design accommodates various wiring configurations while preventing loose connections.

Technical Parameters

Applicable Wire Gauge	0.75-4mm²/28-12 AWG
Temperature range	-25℃~110℃
Rated Voltage	250V
Rated Current	24A
Contact resistance	≤0.015Ω
Insulation resistance	≥1000mΩ
Material	Shell:Nylon PA66/Polycarbon PC(Nyion)UL94V-2(0)
	Contact piece:Brass Tin/plated
	Spring buckle:Imported 301 stainless steel
Reach	15 tests
Allowance	±0.05mm
