Characteristic：
- Quick Installation: Enables easy connection with solid wires, stranded wires, and wires with cold-pressed terminals through a simple insertion action (flexible wires typically require screwdriver assistance to compress or release the spring).
- Constant Force Spring: Utilizes spring elasticity to maintain stable contact pressure, preventing loosening due to vibration or thermal expansion/contraction, ensuring long-term reliability.
- Self-Adaptability: The spring automatically compensates for wire deformation, maintaining low contact resistance.
Dimensions：
Height x Width x Depth：83.5/6.2/46（mm）
Parameters：
Voltage Rating：500（V）
Current Rating：28（A）
Max.load current：32 (A)
Connection data：
Stripping Length：10-12（mm）
Wire section：4 (mm²)
Rigidity wire range：0.2-6 (mm²)
Soft wire range：0.2-6 (mm²)
