KV-M25X

Waterproof Butt Connector KV-M25X
Rated Voltage: 450V
Current Rating: 40A
Wire Section: 0.5mm²-6mm²
Materials: PA66

Specifications

Number of Poles		2Pin/3Pin
Rated Voltage		450V
Current Rating		40A
Wire Section		0.5mm²-6.0mm²
Min Wire Size OD		5-9mm,9-12mm,10-14mm,14-18mm
Temperature Rating		-40℃~+105℃
Waterproof grade IP Code		IP68
Housing Materials		PA66
Terminal Material		Nickel-Plated Brass

×
