KV222-4

Applicable Wires: 0.2-4 mm²

Operating temperature: -25℃~95℃

Rated voltage: 250V

Rated current: 32 A

Material of connectors shell: Nylon PA66/Polycarbon PC

Material of conductive parts: Brass Tin/plated

Characteristics:

Simplified Wiring Solution: The white-shell KV222-4 lever terminal block enables quick, tool-free connections for diverse applications from intercoms to electric ovens.
High-Capacity Performance: Rated for 250V/32A operation, it securely handles wires from 0.2-4mm² for reliable high-load connections.
Maintenance-Free Convenience: Features our proven, fuss-free connection technology that requires no special wire preparation for instant, secure terminations.

Technical Parameters

Applicable Wire Gauge	0.2-4mm²/28-14AWG
Temperature range	-25℃~95℃
Rated Voltage	250V Ac/Dc
Rated Current	32A
Contact resistance	≤0.015Ω
Insulation resistance	≥1000mΩ
Material	Shell: Nylon PA66/Polycarbon PC(Nyion)UL94V-2(0)
	Contact piece: Brass Tin/plated
	Spring buckle: Imported 301 stainless steel
Reach	15 tests
Allowance	±0.05mm
