KV222-6

Applicable Wires: 0.5-6 mm²

Operating temperature: -25℃~95℃

Rated voltage: 600 V

Rated current: 35-50 A

Material of connectors shell: Nylon PA66/Polycarbon PC

Material of conductive parts: Brass Tin/plated

Characteristics:

Effortless High-Power Connections: The black KV222-6 lever terminal block delivers tool-free, 600V/30-50A capacity for demanding applications from ovens to intercom systems.
Universal Wire Compatibility: Accommodates 0.5-6mm² conductors (solid/stranded/fine-stranded) without preparation, streamlining installations.
Industrial-Grade Simplicity； Combines maintenance-free operation with secure lever-clamp technology for professional-grade results in commercial/residential projects.

Technical Parameters

Applicable Wire Gauge	0.5-6mm²/20-10 AWG
Temperature range	-25℃~95℃
Rated Voltage	600V Ac/Dc
Rated Current	35-50A
Contact resistance	≤0.015Ω
Insulation resistance	≥1000mΩ
Material	Shell: Nylon PA66/Polycarbon PC(Nyion)UL94V-2(0)
	Contact piece: Brass Tin/plated
	Spring buckle: Imported 301 stainless steel
Reach	15 tests
Allowance	±0.05mm
