KV436

Characteristics:

Premium Safety & Durability: The KV436(3 in 6 out) lever terminals feature advanced flame-retardant PA66/PC construction for superior heat resistance and long-lasting performance in demanding environments.
Smart Quick-Connect Design: With an intuitive lever mechanism, installation is effortless—just lift, insert (0.5-4.0mm²), and snap closed for instant, secure connections.
Compact Yet Industrial-Grade: Engineered for space efficiency without compromising strength, these terminals deliver professional reliability for high-end commercial and industrial applications.

Technical Parameters

Applicable Wire Gauge	0.5-4mm²/28-12 AWG
Temperature range	-25℃~95℃
Rated Voltage	250V/600V
Rated Current	32A
Contact resistance	≤0.015Ω
Insulation resistance	≥1000mΩ
Material	Shell: Nylon PA66/Polycarbon PC(Nyion)UL94V-2(0)
	Contact piece: Brass Tin/plated
	Spring buckle: 301 stainless steel
Reach	15 tests
Allowance	±0.05mm
Suitable guide	TH35-7.5
