Characteristics:
- Reliable Fastening: Screw crimping ensures secure connections and vibration resistance.
- Straight-Through Design: Wires pass directly through, minimizing bending and reducing resistance.
- Strong Compatibility: Supports multiple wire diameters for easy installation and maintenance.
Dimensions：
Height x Width x Depth：43/4.2/41（mm）
Parameters：
Voltage Rating：500（V）
Current Rating：17.5（A）
Max.load current：17.5 (A)
Connection data：
Stripping length：7（mm）
Wire section：1.5 (mm²)
Rigidity wire range：0.4-1.5 (mm²)
Soft wire range：0.4-1.5 (mm²)
