Characteristic:
- Quick Wiring: Press-to-release spring mechanism enables fast connection, significantly improving installation efficiency.
- Reliable Contact: Constant spring force ensures vibration/shock resistance and long-term stable connection.
- Self-locking & Anti-loosening: Spring plate automatically locks wires to prevent disconnection from external pulling.
Dimensions：
Height x Width x Depth：60.5/4.2/35.5（mm）
Parameters：
Voltage Rating：500（V）
Current Rating：17.5（A）
Max.load current：17.5 (A)
Connection data：
Stripping length：8-10（mm）
Wire section：1.5 (mm²)
Rigidity wire range：0.08-1.5 (mm²)
Soft wire range：0.08-1.5 (mm²)
