Characteristic:
- Quick Wiring: Press-to-release spring mechanism enables fast connection, significantly improving installation efficiency.
- Reliable Contact: Constant spring force ensures vibration/shock resistance and long-term stable connection.
- Self-locking & Anti-loosening: Spring plate automatically locks wires to prevent disconnection from external pulling.
Dimensions：
Height x Width x Depth：69.5/8.2/42.5（mm）
Parameters：
Voltage Rating：1000（V）
Current Rating：41（A）
Max.load current：52 (A)
Connection data：
Stripping length：12（mm）
Wire section：6 (mm²)
Rigidity wire range：0.2-10 (mm²)
Soft wire range：0.2-6 (mm²)
