RNB 60

Ring non-insulted terminal

Cable size:50-70 mm²

Max current:215 A

Material:Copper

Ring non-insulted terminal

Cable size:50-70 mm²

Max current:215 A

Material:Copper

Technical Parameters

ITEM NO.	USA SCREW	d2ø (mm)	Dimension(mm)
ITEM NO.	USA SCREW	d2ø (mm)	B	L	F	E	Dø	dø	Explanation
RNB 60-6	1-4	6.4	22.0	49.7	20.7	18.0	15.4	11.4	Cable size:50-70mm²(AW.G1/0) Max current.Imax=215A Material:Copper Thickness:1.8mm Plating:Tin
RNB 60-8	5-16	8.4
RNB 60-10	3-8	10.5
RNB 60-11	7-16	11.5
RNB 60-12	1-2	13.0
RNB 60-14	9-16	15.0	32.0	57.5	23.5
RNB 60-16	5-8	17.0
RNB 60-18	11-16	19.0
RNB 60-20	3-4	21.0
RNB 60-22	7-8	23.0

×
